Shielded 300mm RG316 Custom Wire Harness Assembly

RF Cable TS9 Bent Male To SMA-K Female RG316 High Temperature Shielded Wire Communication Wires And Cables

Product features:

Feeder, jumper, patch cord. Suitable for connecting radio frequency cables or microstrip lines in radio frequency circuits of microwave equipment and digital communication systems

Parameters:

About RF Cable:

Radio frequency is referred to as RF. Radio frequency is radio frequency current, which is an abbreviation for a high-frequency alternating electromagnetic wave. An alternating current that changes less than 1,000 times per second is called a low-frequency current, and more than 10,000 times is called a high-frequency current, and radio frequency is such a high-frequency current. The cable television system adopts radio frequency transmission.

The so-called RF cable is a high-frequency transmission cable

The structure of the radio frequency cable, from the outside to the inside, is a sheath, an outer conductor (shield layer), an insulating medium, and an inner conductor.

The sheath, that is, the outermost layer is an insulating layer, plays a protective role. Outdoor cables should use black polyethylene with excellent climate characteristics. Indoor users should use light-colored polyethylene for aesthetic reasons.

The outer conductor (shield layer), the outer conductor of the RF cable has a dual role. It not only serves as a conductor of the transmission loop, transmits low levels, but also has a shielding effect. The outer conductor usually has three structures.

(1) Metal tube. This structure is welded by copper or aluminum tape longitudinally wrapped or extruded and drawn by seamless copper tube. This structure has the best shielding performance but poor flexibility and is often used in trunk cables.

(2) The vertical package of aluminum-plastic composite tape overlaps. This structure has good shielding effect and low manufacturing cost, but because the outer conductor is a round tube with a longitudinal slit, the electromagnetic wave will penetrate through the slit and leak, so it should be used with caution.

(3) Combination of braided mesh and longitudinal package of aluminum-plastic composite tape. This is developed from a single woven mesh structure, which has the characteristics of good flexibility, light weight and reliable joints. Experiments have shown that the use of a reasonable composite structure has greatly improved the shielding performance. Used heavily.
