UL2651 28 AWG Wire 2.54MM 40 Pin IDC Cable

40P IDC Ribbon Cable Gray Cable 2.54MM Pitch UL2651 Product Positive Marking Cable

Product introduction

A ribbon cable is a flat, thin cable composed of multiple small-grade cables placed parallel to each other. With each core situated side by side, they form a wide-flat cable resembling a piece of ribbon, hence its name. This type of cable is mostly used in electronic systems that require multiple data buses to link internal peripherals, such as disk drives to their respective drive controllers.

Features:

1. Small size and light weight is the only solution to meet the requirements of miniaturization and movement;

2. It can be moved, bent and twisted without damaging the wire, and can meet different shapes and special package sizes;

3. The IDC Ribbon cables has excellent electrical properties, dielectric properties and heat resistance;

4. The IDC Ribbon cables has higher assembly reliability and quality.

Parameters:

All crimping methods at both ends of the IDC cable:

(1) In the same direction, the convex points are consistent

The direction du of the two baiIDC crimping heads is the same, and the direction of the bumps is also the same. The conventional pressing method of three zhi angles to the red edge is also called dao one-to-one pressing method. Eighty-five percent of customers use this pressing method! 6-34P can be crimped with an automatic pressing machine.

(2) In the same direction, the convex points are opposite

The direction of the two IDC crimping heads is the same, and the direction of the bumps is opposite. Everyone will ask how the bumps are different. The two-piece buckle is the direction of the three-piece buckle! The conventional method is to make three-piece, so here we are talking about the three-piece directional bump!

(3) In the same direction, the convex points are opposite

The direction of the two IDC crimping heads is the same, and the direction of the bumps is opposite. The upper one is a three-piece type, and the lower one is a two-piece type with no reverse buckle! The three-piece direction bumps are subject! If you need a two-piece type, pay attention!

(4) Positive and negative, the convex points are consistent

The direction of the two IDC crimping heads is opposite, and the direction of the bumps is the same. The upper one is a three-piece type, and the lower one is a two-piece type without a back buckle! The conventional is to make a three-piece type, so here we are talking about the three-piece direction bumps!

(5) Positive and negative, convex points are opposite

The directions of the two IDC crimping heads are opposite, and the directions of the bumps are opposite, which means the opposite. The upper one is a three-piece type, and the lower one is a two-piece type without a back buckle! The conventional is to make a three-piece type, so here we are talking about the three-piece direction bumps!

(6) One positive and one negative, the convex points are relative

The direction of the two IDC crimping heads is opposite, and the direction of the bumps is opposite. The upper one is a three-piece type, and the lower one is a two-piece type without a back buckle! The conventional is to make a three-piece type, so here we are talking about the three-piece direction bumps!

The above six crimping methods are all crimping methods at both ends of the finished IDC cable. These six crimping methods are used in IDC gray cables with different positioning!
