12V 5A AC DC Power Supply Adaptor ETL RoHS Listed

Name: 12V 5A AC DC Power Supply Adaptor ETL RoHS Listed
Brand: Sanyouhe
SKU: SYH-P021
Availability: InStock
ISBN: 13867389

Product Details:

Place of Origin:	JIANGSU,CHINA
Brand Name:	Sanyouhe
Certification:	UL、IATF、ISO
Model Number:	SYH-P021

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	100/200/300/500pcs per bag , then outside carton； Inner packing : PE bag / Bubble paper / plastic box ； Outer packaging : Carton Box / Custom packaging / Pallet / Wooden box
Delivery Time:	4-10 working days
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	35000 PCS/per week

Contact Now

Detailed Product Description

Product Name:	Power Adapter	Service:	OEM ODM Accept
Material:	Copper/pa66/pbt/high Temp	Length:	Customized Length
Color:	Customized Color	Sample:	Avaliable
Certification:	ISO9001:2008
High Light:	12V 5A Power Supply Adaptor , RoHS Power Supply Adaptor , ETL AC DC Power Adapter

Wall Charger/Power Supply Adaptor/AC DC Power Adapter with UL ETL CE FCC RoHS SAA C-tick PSE

12V5A desktop power adapter

1. universal input voltage, voltage stabilizing precision, with overload protection, over-voltage protection, short-circuit protection, overheat protection
2. little output riple
3.100% loaded aging
4. high safety, good looking, easy to use

Input/Output Specifications :
RatedVoltage:100~240Vac:	AC 100-240,50/60Hz
VariationRange:90-264Vac:	AC 90-264, 47/63Hz
Input Current:	0.35Amps max At any input voltage and rated, DC output rated load.
Inrush Current:	80 Amps Max. Cold start at 240Vac input, with rated load and 25ºCambient.
Ac Leakage Current:	0.25mA Max.At240Vac input
Output Power	60W
Output Voltage	12V
Line Regulation	±1%
Load Regulation	±5%
Over Voltage Protection	120%min
Over Current Protection	120%min
Short-cut Protection	Auto recover
Operating Temperature:	0ºCto 40ºC,Full load, Normal operation
Storage Temperature	20ºCto 80ºC

Features :

Universal AC input/Full range(up to 264Vac)
Protection: Short Circuit/Over Current/Over temperature/Over Voltage
High efficiency, long life and high reliability
100% full load burn-in test
Class II design
UL ETL CE FCC RoHS SAA C-tick PSE KC Level VI Standards

Trade Term :

Payment term: PayPal, Western Union, T/T,etc
Leading time:7-9 working days
Sample: 3-5 working days after payment confirmed
Freight cost: Customers's shipping agent or our forwarder

FAQ :

Q: How many Voltage you can supply?
A: 5V 6V 9V 10V 12V 16V 28V 29V 24V 36V 48V.

Q: How many current you can supply?
A: 0.5A 1A 1.5A 2A 2.5A 3A 3.5A 4A 5A 10A 15A 20A 30A 40A.

Q: Are you manufacturer?
A: We are a professional power supply manufacturer with high reputation in this field.

Q. Do you have certificates for your products?
A: Yes,we have UL,ETL,FCC,RoHS,CE,KC,SAA, PSE,REACH and DOE Level VI Standard Certifications.

Q: What is your samples lead time or goods delivery time?
A: Samples time about 3 working days,goods time about 12 working days.

Q: Can we print our logo?
A: We can print your logo on both power adapter and package.

Why Choose US:

More than ten years experience of power supply manufacturer(2.5W-1200W Power Supply All Optional)
Professional team for after-sale service 7*24
Experienced R & D team and profesional sales team
OEM & ODM service, we will evaluate, design and produce your customized products
Offer confidentiality agreement to protect your profit, with us your business will be in safe your money in safe.
Meet the safety requirements of various countries.
Meet the environmental protection RoHS requirements of various countries.
Meet the requirements of conducting radiation (EMC/EMI) of various countries.
